1.Product Introduction

This intelligent lighting power saver is installed at the front end of the line, and the working curve of the power saving system can be automatically controlled through the built-in intelligent controller or programmable controller,  astronomical clock , bright controller, etc., so as to easily control the load on the entire line , The power saving rate is as high as 20%~40%, which extends the life of the light source and accessories by two to three times, and reduces the overall operating cost by more than 30% to 50%. Compared with other current domestic lighting energy-saving solutions, this solution has its own uniqueness in terms of energy-saving control technology and lower operating costs.

Intelligent street lamp energy-saving system take a microcomputer as the core , built-in power-saving software to optimize the power supply rate of light with and real-time monitoring and phase tracking. Automatically smoothly adjust voltage and current amplitude of the light circuit, improving the power factor of the lighting circuit system, reducing the operating temperature of the lamps and lines, to ensure that the light can work under normal conditions, to let the lights own the   the best light power, reducing the lighting caused by overcharging glare, so that the light emitted more soft, lighting distribution more balanced , but it also can greatly reduce the proportional power.

2. Working Environment

Ambient temperature: -15°C~+40°C

Relative humidity; ≤90%

Altitude: ≤1000m

No vibration or bumps in the installation site

There is no gas, steam, chemically deposited dust, dirt and other explosive and corrosive media that seriously affect the voltage and insulation.

·Large-screen LCD display

Using large LCD screen, can dynamically display the working voltage, working current, and various working conditions.

·Non-contact (Or stepless )Voltage Regulation

Between 180V ~ 230V, user could select the output voltage value and time period of output voltages changes arbitrarily. Base on the setting time,  Power Saver will automatically and slowly changes the output voltage as the setting value .

·Time Control

Eight periods per day can be set, each period can output different power-saving voltage (arbitrarily determined).

·Wide Input Voltage Swing Ranges

Input Range  can be customized fr om - ±15% to ±60%

·High Precision for the Output Voltage

Output Voltage Accuracy could be ±1% (±1% to ±5% adjustable)

·Multi-protection Design

Highly reliable and endurable design.   With the protection of over-voltage, under-voltage ,over-load, short-circuit, manual bypass.

·Independent Phase Control

Three - phase input and output  are adjusted separately to achieve balance so that the equipment can operate normally. This type voltage stabilizer has higher accuracy and more stable operation.

·Rain Proof Enclosure, Corrosion Resistant

Adopt rainproof design, can effectively prevent rainwater splashing. The product adopts the whole high temperature spray paint treatment, the anti-corrosion is high.

This product is widely used for municipal lighting projects, highway renovation projects, road lighting upgrade projects, urban comprehensive renovation construction projects, roads and supporting projects, road network construction projects, street lamp special change installation projects, etc.
